MAK smart 150 alternate motion cartoner for pharma, herbal, nutraceutical, cosmetic and food market

cartoning packaging machine mak 130

cartoning packaging machine pharma market ready.

When we have conceived the mak smart 150 our focus was to offer at our customer a machine that can guarantee an easy operating cycle.
In order to reach our goal whe use the most advanced technologies in the packaging market mixed with innovative mechanical solutions. The results of all those efforts is our automatic cartoning packaging machine Mak smart 150, that in only 3450mm of length reaches the output speed of 100 cartons per minute.

.

Compact: Only 3,45 m in length to reduce the space and save money.

Adapted: GUK folding and inserting unit for leaflet.

Top in quality: Equipped with Siemens PC, drives, and brushless motors.

Easy to use: 15″ operator panel with an easy  and intuitive human interface.

Worker friendly: Extremely accessible to ensure easy cleaning and use.

Super fast format changing: Easy and very fast format changing.

Reliable: New technology cartons feeding system

Safety: Control photocell detects the presence of the products in the feeding unit

MAK smart 150

Cartoning packaging machine

Technical specifications



Maximum output per minut: up to 100 cartons
Space required

Machine length:    approximately 3450 mm

Machine hight:      approximately 1551mm

Machine width:     approximately 1700mm

Machine net weight approximately 2100 Kg
Installed power 7,5 Kw
Inlet air pressure 6/8 bar
Average compressed air consumption 200 N/L min (1bar)
Cartons dimension

A min 30 mm max 110 mm

B min 16 mm max   78 mm

C min 80 mm max0160 mm



TECHNICAL SPECIFICATIONS

Max. output per min.
up to/ 100 cartons

Space required:
Machine length: approx. 3450 mm
Machine width:  approx. 1700 mm
Machine hight:   approx. 1551 mm

Machine net weight
approximately 2189 Kg

Installed power
7,5 Kw

Inlet air pressure
6-8 bar

Cartons dimension
A
min 30 mm max 110 mm
B
min 16 mm max   78 mm
C
min 80 mm max 160 mm

%

compactness

%

speed

%

ease of use

%

reliability

THE ART OF CARTONING MACHINES
